  • Parameter

The machine use pressure to control the lifting of the polisher, the pressure can be adjust. The swinging beam drives the polisher to move, the moving speed can be adjust.

Belt type feeding plate working table,belt running speed can be adjusted; The electrical system use PLC and man-machine interface.

As a grinding and polishing equipment for marble or imitation stone production line, to make a smooth and flat surface.

Number of conveying belt

1 slip

Number of polishing head

14pcs

Dia of the polishing head

100mm

Number of chamfering wheel

6pcs

Dia of chamfering wheel

150-200mm

Number of notching disc

3-4 slip

Dia of notching disc

150mm

Working width

100-1200mm

Working thickness

6-30mm

Polishing speed

2-6m/min

Total power

32kw

Water consumption

490L/min

Lectricity consumption

20kw/h

Air consumption

55L/min

Outline dimension

6000x2200x1700MM

Weight

5T
